Wide range of profile cutting services, delivering a clean, tidy cut to your exact requirements.

Variety of Quality Steel Cutting Services

From quotation to delivery, RMP Products guarantees precision, quality and exceptional customer service on every profile cutting project. Our experienced team works with a wide range of non-ferrous steels, from 3mm to 300mm thick, cutting each plate or profile to your exact measurements and specifications.

We’re proud to operate Europe’s first Twin Head Viper Plasma Cutting Machine alongside multiple flame cutting beds, allowing us to serve as your complete solution for all steel profiling requirements.

Every project is backed by our ISO 9001 certification and UKCA Execution Class 4 approval. We also provide high-quality steel finishing services, ensuring your order arrives ready for immediate assembly.

Steel Cutting For Over 30 Years

Offering bespoke steel profile cutting solutions and a complete end-to-end service.

Our Steel Profile Cutting Methods

Flame Cutting

Our flame cutting service is ideal for thicker materials, capable of handling steel plates up to 300mm thick with precision. This traditional method uses a chemical reaction between oxygen and steel to create clean, professional cuts.

This method is perfect for projects where slightly rounded edges are acceptable or even beneficial, as it often requires minimal finishing. Many customers find flame cutting to be a cost-effective solution for heavy-duty materials, providing excellent value without compromising on quality.



Plasma Cutting

For faster turnaround on thinner materials, our plasma cutting service delivers exceptional speed and precision. This process uses highly conductive gas to cut through steel quickly and efficiently.

The speed of plasma cutting particularly suits large-scale production requirements, allowing us to process substantial quantities in minimal time. The precision of this method also ensures complex designs are executed with exacting accuracy.

Choosing the Right Plate Cutting Method for Your Project

Choosing the correct steel cutting method for your project depends on several factors, including the thickness of the material, the level of detail required and your timescale.

For steel plates over 60 millimetres, flame cutting is often the most effective option. For materials between 3 and 60 millimetres, plasma cutting delivers excellent results, especially for detailed steel profiles.

Our team can help you decide which option suits your project best and ensure the end result meets your expectations.

Profile Cutting Process

  • Submit your specifications – Send us your cutting order & requirements
  • CAD Work – Draw out the specific profile size on our CAD package.
  • Precision cutting – Your steel plate/profile cut to size with the highest accuracy
  • Quality inspection – All profile cutting undergoes rigorous quality checks
  • Finishing services – Additional treatments available as required
  • Nationwide delivery – Fast, secure transportation of your finished pieces

Steels We Cut

Hot Rolled & Cold Rolled Structural Steels

S275JR, S275JR+N
S355JR, S355J2+N, S355K2+N

Wear Resistant & High Strength Steels

400 Brinell, 450 Brinell, 500 Brinell (Various Brands)
S690, S690QL, 700mc (Various Brand)

Weather Resistant Steels

S355J2W, S355J2W+N

Medium Carbon Steels

EN10083-2 (EN8) 080M40

Offshore Steels

S355G8+N, S355G10+N, S420G2+M

Pressure Vessel Steels

P265gh, P295GH, P355GH, P275NL2/NL1, P355NL2/NH, P460NL2/NH

Steel Cutting Service Data & Tolerances

Plasma Cutting Technical Data
Maximum Cutting Length 16 Metres 10 Metres
Maximum Cutting Width 5 Metres 2.5 Metres
Minimum Cutting Thickness 3mm 3mm
Maximum Cutting Thickness 60mm 50mm

Plasma Cutting Tolerances
<40mm +/-1.5mm
41-60mm +/-2mm



Flame Cutting Technical Data
Maximum Cutting Length 6 Metres
Maximum Cutting Width 4 Metres
Minimum Plate Thickness 5mm
Maximum Plate Thickness 300mm

Flame Cutting Tolerances
<40mm +/-1.5mm
41-60mm +/-2mm
61-80mm +/-3mm
81-100mm +/-4mm
101-150mm +/-6mm
150mm+ +/-6mm

Steel Profile Cutting FAQs

What is your minimum/maximum thickness capability for steel cutting?

Our steel cutting capabilities range from 1mm to 400mm thickness, depending on the specific service.

What tolerances can you achieve with your steel plate cutting services?

For both plasma and flame cutting up to 40mm we maintain +/-1.5mm accuracy, while thicker materials follow increasing tolerances up to +/-6mm for plates over 150mm thick.

What types of steel can you cut with your profile cutting services?

Our versatile cutting capabilities allow us to process virtually all non-ferrous steel materials including mild steel to meet different industrial requirements.

What is the maximum thickness of steel plate you can cut?

We can cut steel plates up to 300mm thick using our flame cutting equipment, while recommending plasma cutting for optimal results on materials between 6mm and 38mm.

Do you provide material certification with your steel plate cutting services?

Yes, we provide full material certification and traceability documentation with all our cut steel products, including mill certificates and processing details that satisfy CE Execution Class 4 requirements.

Can you handle small batch or one-off profile cutting requirements?

We accommodate everything from one-off bespoke profiles to large production runs with our flexible production setup, pricing fairly regardless of order size.

Other Services We Offer

To compliment our profile cutting services, we also offer these:

CNC Machining

Full suite CNC machining services delivering high quality parts to your specifications (up to 1620mm x 810mm), including milling and drilling from 3mm to 32mm. Our four CNC centres and Gemini machine with an eight head tool changer ensure precision across all operations.

Bevelling and Chamfering

We provide high quality weld profile bevels on plates from 3mm to 300mm thick with angles up to 30 degrees. Our services cover everything from uniflats and base plates to chamfered profiles, bridge components, deck plates and custom steel profiles.

Shotblasting

Industrial shot blasting services that deliver a smooth and durable finish to your steel parts with expert precision. Using our rotary barrel tumble blaster and rotary table blaster, we can work with parts of all sizes, ensuring every piece is finished to the highest standard and level of detail.
